5kw 10kwh 48v Lifepo4 Home Battery 200Ah Rechargeable 16S1P Prismatic Cell

5kw 10kwh 48v Lifepo4 Home Battery 200Ah Rechargeable 16S1P Prismatic Cell

Product Details:

Place of Origin: Guangdong, China
Brand Name: YABO
Certification: CE/IEC/RoHS/UN38.3/FCC/MSDS
Model Number: YB-WM48200H

Payment & Shipping Terms:

Price: $2,500.00/pieces 1-99 pieces
Packaging Details: Standard Report Plastic Bag, Carton, Pallet.
Supply Ability: 50000 Piece/Pieces per Month
Get Best Price Contact Now

Detail Information

Battery Type: LiFePO4 Nominal Voltage: 51.2Volts
Nominal Capacity: 200Ah Energe: 10240Wh
Product Name: Power Battery Wall Cycle Life: 4000-6000+ Cycles
Casing: Sheet Metal Case Application: Home Energy Storage,powerwall
Gross Weight: About 88kg Dimension: 420*600*230mm
Port: Shenzhen Or HK
High Light:

10kwh 48v Lifepo4 Home Battery

,

lifepo4 5kw 48v battery

,

200ah lifepo4

Product Description

Hot Sales Power Storage Power Wall Lithium Ion Battery Pack 5kw 10kw 48V 200Ah Rechargeable 16S1P Prismatic Battery Cell

Lithium Powerwall are widely used in Solar Systems for residential and commercial use. With more than 3000 times
deep cycle, up to 90% DOD and phosphate battery Cell, HHS Powerwall has won global approval!



Specification
Basic parameters:
Model: YB-WM48200H
Capacity: 200Ah(10kwh)
Voltage: 51.2V

Built-in battery parameters:
Voltage at end of Discharge: >40V
Charging Voltage: 58.4V
Material: SPCC
Internal Impedance: ≤20mΩ
Recommended charging current: 0.2C
Recommended discharging current: 0.2C
Maximum charge Current: 200A(0~45℃)
Maximum Discharge Current: Constant current 200A
Water Dust Resistance: IP55
Operation Temperature Range: Charge 0~45℃, Discharge -10~55℃
Great Cell: high cycle A+ product, 16S1P

Appearance parameters:
Size: 420*600*230mm
Cycles: 4000~6000+
Gross weight: About 88kg
Warranty: 5 years

Details Images
5kw 10kwh 48v Lifepo4 Home Battery 200Ah Rechargeable 16S1P Prismatic Cell 0
5kw 10kwh 48v Lifepo4 Home Battery 200Ah Rechargeable 16S1P Prismatic Cell 1
5kw 10kwh 48v Lifepo4 Home Battery 200Ah Rechargeable 16S1P Prismatic Cell 2
5kw 10kwh 48v Lifepo4 Home Battery 200Ah Rechargeable 16S1P Prismatic Cell 3
5kw 10kwh 48v Lifepo4 Home Battery 200Ah Rechargeable 16S1P Prismatic Cell 4
5kw 10kwh 48v Lifepo4 Home Battery 200Ah Rechargeable 16S1P Prismatic Cell 5
Why Choose Us
5kw 10kwh 48v Lifepo4 Home Battery 200Ah Rechargeable 16S1P Prismatic Cell 6
Application
5kw 10kwh 48v Lifepo4 Home Battery 200Ah Rechargeable 16S1P Prismatic Cell 7
5kw 10kwh 48v Lifepo4 Home Battery 200Ah Rechargeable 16S1P Prismatic Cell 8
Company Profile
5kw 10kwh 48v Lifepo4 Home Battery 200Ah Rechargeable 16S1P Prismatic Cell 9
5kw 10kwh 48v Lifepo4 Home Battery 200Ah Rechargeable 16S1P Prismatic Cell 10

Shenzhen YaBo Power Technology Co.,Ltd. YABO power Technology Co.,Ltd is a new energy company, at least 20 years professional
battery manufacturing experience, Has a strong R & D team, design team, business team.Mainly engaged in LiFePO4 battery ,energy storage battery packs,portable power station,mainly providing new energy battery products related to home solar energy storage and outdoor electrical power supply for responding to the national goal of achieving carbon neutrality, reducing carbon emissions and bringing green new energy to the world.



YABO power products are distributed worldwide for use in various electronic products, these include: Wireless communication devices, UPS,Tower Base Station, RV,golf carts,forklifts,yachts,lighting, electrical tools, toys, medicalequipment, solar energy storage systems,backup power systems and electric vehicles.Our batteries have passed ISO9001, CE, RoHS,cB, REACH, FCC, UN38.3 and UL certification.



As a leading worldwide supplier, YABO power current distribution network includes China,Hong Kong, North America, Europe, South America, Southeast Asia and Korea.Our lithium ion, lithium polymer, LiFePO4 batteries,solar generator show high energy
density of 300wh per kg, long cycle life exceed 2,000 cycles, wide temperature work range from -40"C~+ 6 5"C. Currently we are the only supplier of ultra-high power. We believe that our reliable quality products and strong relationships with consumers is
the key to our success. Top technology, Top quality, Top service which is always our aim.With great enthusiasm and loyalty, we are willing to provide you with perfect services,and work together with you to create a better future.





5kw 10kwh 48v Lifepo4 Home Battery 200Ah Rechargeable 16S1P Prismatic Cell 11
Packaging & Shipping
5kw 10kwh 48v Lifepo4 Home Battery 200Ah Rechargeable 16S1P Prismatic Cell 12
5kw 10kwh 48v Lifepo4 Home Battery 200Ah Rechargeable 16S1P Prismatic Cell 13
5kw 10kwh 48v Lifepo4 Home Battery 200Ah Rechargeable 16S1P Prismatic Cell 14
FAQ

Q1. Can I have a sample order?

A. Yes, we welcome sample order to test and check quality.

Q2. What about the lead time?

A. Sample needs 3 days, mass production time needs 5-7 weeks, it depends on order quantity.

Q3. Do you have any MOQ limit?

A. Yes, we have MOQ for mass production, it depends on the different part numbers. 1~10pcs sample order is available. Low MOQ, 1pc for sample checking is available.

Q4. How do you ship the goods and how long does it take to arrive?

A. It usually takes 5-7 days to arrive. Airline and sea shipping is also optional.

Q5. How to proceed with an order?

A. Firstly let us know your requirements or application. Secondly, We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places a deposit for formal order. Fourthly We arrange the production.

Q6. Is it OK to print my logo on the product?

A. Yes. Please inform us formally before our production and confirm the design firstly based on our sample. Q7.Which certificates do you have?

A:We have CE/FCC/ROHS/UN38.3/MSDS ...etc.

Q8. How about warranty?

A:3 year warranty.
