• Lithium Ion Battery Pack Waterproof Prismatic Cell Lifepo4 16s 48v Bms 100ah
  • Lithium Ion Battery Pack Waterproof Prismatic Cell Lifepo4 16s 48v Bms 100ah
  • Lithium Ion Battery Pack Waterproof Prismatic Cell Lifepo4 16s 48v Bms 100ah
Lithium Ion Battery Pack Waterproof Prismatic Cell Lifepo4 16s 48v Bms 100ah

Lithium Ion Battery Pack Waterproof Prismatic Cell Lifepo4 16s 48v Bms 100ah

Product Details:

Place of Origin: China
Brand Name: YABO
Certification: CE、ROHS、FCC、IEC、UN38.3、MSDS
Model Number: YB-WP48100

Payment & Shipping Terms:

Minimum Order Quantity: 1PCS
Price: 900-1200 USD/PCS
Packaging Details: Standard Report Plastic Bag, Carton, Pallet.
Delivery Time: 7-15 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50000PCS/Month
Get Best Price Contact Now

Detail Information
Color: Black Casing: Metal
Cycle Life:: 》2000 Cycles IP Level: IP67
Dimension: 380*320*340mm Model: 48V 100Ah-Waterproof Case
High Light:

prismatic lfp cells

,

lifepo4 prismatic 100ah

,

16s bms 48v

Product Description

Lithium Ion Battery Pack Waterproof Prismatic Cell Lifepo4 16s 48v Bms 100ah

Place of Origin:
Guangdong, China
Brand Name:
YABO
Model Number:
48V 100Ah-Waterproof case
Product Name:
48V 100Ah waterproof Lithium Iron Phosphate (LiFePO4) Battery
Cycle Life:
2000+ Times
Dimension:
380*320*340mm
MOQ:
1 Pc
Samples Time:
3 days
Cell & Format:
3.2v 100ah (16S1P)
Casing:
Metal
Water Dust Resistance:
IP67
OEM/ODM:
Warmly Welcomed
Warranty:
3years
Application:
BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, Electric Folklifts, electric vehicles, Solar Energy Storage Systems, UPS, Wind Power System,Electric Vehicle , E-bike, E-rickshaw etc,Lighting
Battery Cell:
3.2v 100Ah
Certification:
CE, ROHS, FCC, IEC, UN38.3, MSDS
Weight:

The charging current:
100A
The discharge current:
100A

Lithium Ion Battery Pack Waterproof Prismatic Cell Lifepo4 16s 48v Bms 100ah 0
Product Description
Electrical
Characteristics
Nominal Voltage
51.2V
Nominal Capacity
100Ah@0.2C
Energy
5120 Wh
Internal Resistance
≤35mΩ
Cycle Life
2000 Cycles @ 0.2C Charging/Discharging ,Until 70% Capacity
Self Discharge
≤3.5% per month at 25℃
Standard Charging
Max.Charging Voltage
58.4±0.2V
Charging Mode
At 0℃~45℃ temperature, charged to 58.4V at a constant current of 0.2C, and then,changed continuously with constant voltage of 58.4V until the current was not more than 0.02C
Charging Current
100A
Max.Charging Current
100A
Standard Discharging
Discharging Current
100A
Max. Continuous Current
100A
Max.Pulse Current
110A(<10S)
Discharging Cut-off Voltage
40. V
Operating Condition
Charge Temperature
0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
Discharge Temperature
-20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity
Storage Temperature
0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
Water Dust Resistance
IP67
Structure
Cell & Format
 3.2V 100 Ah cells
Casing
Waterproof  Metal  case
Dimension(L*W*H*TH)
380*320*340mm
Package Dimension

Weight

Display panel

Details Images



Lithium Ion Battery Pack Waterproof Prismatic Cell Lifepo4 16s 48v Bms 100ah 1
Lithium Ion Battery Pack Waterproof Prismatic Cell Lifepo4 16s 48v Bms 100ah 2
Lithium Ion Battery Pack Waterproof Prismatic Cell Lifepo4 16s 48v Bms 100ah 3







Test Chart
Lithium Ion Battery Pack Waterproof Prismatic Cell Lifepo4 16s 48v Bms 100ah 4
Product Advantage



◆ Using lithium iron phosphate cell, superior safety,thousands of cycles.
◆ Built-in automatic protection for over-charge, over discharge, over current and over temperature.
◆ No need of maintenance .
◆ Internal cell balancing.
◆ Lighter weight: About 40% ~50% of the weight of a comparable lead acid battery.
◆ Can be charged using most standard lead-acid charger (set).
◆ Wider temperature range:-20℃~60℃.
◆ Support for Series application expansion (up to 51.2V) and two in parallel.
Application
Lithium Ion Battery Pack Waterproof Prismatic Cell Lifepo4 16s 48v Bms 100ah 5
◆ UPS ◆ Solar &Wind Power System ◆ Golf Cart ◆ Electric Vehicle , E-bike, E-rickshaw etc. ◆ Lighting
Why Choose Us
Lithium Ion Battery Pack Waterproof Prismatic Cell Lifepo4 16s 48v Bms 100ah 6
Product Packaging
Lithium Ion Battery Pack Waterproof Prismatic Cell Lifepo4 16s 48v Bms 100ah 7
Lithium Ion Battery Pack Waterproof Prismatic Cell Lifepo4 16s 48v Bms 100ah 8
Lithium Ion Battery Pack Waterproof Prismatic Cell Lifepo4 16s 48v Bms 100ah 9
FAQ
Q1. Can I have a sample order?
A. Yes, we welcome sample order to test and check quality.

Q2. What about the lead time? A. Sample needs 3 days, mass production time needs 5-7 weeks, it depends on order quantity.

Q3. Do you have any MOQ limit? A. Yes, we have MOQ for mass production, it depends on the different part numbers. 1~10pcs sample order is available. Low MOQ, 1pc for sample checking is available.

Q4. How do you ship the goods and how long does it take to arrive? A. It usually takes 5-7 days to arrive. Airline and sea shipping is also optional.

Q5. How to proceed with an order? A. Firstly let us know your requirements or application. Secondly, We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places a deposit for formal order. Fourthly We arrange the production. production and confirm the design firstly based on our sample.

Q6. Is it OK to print my logo on the product?
A. Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q7.Which certificates do you have?
A:We have CE/FCC/ROHS/UN38.3/MSDS ...etc.

Q8.How about warranty?
A:3 year warranty.
