12v 48v 72v 100ah 200ah 170ah Lifepo4 Battery Deep Cycle BMS Lithium
Product Details:
Place of Origin: | Guangdong, China |
Brand Name: | YABO |
Model Number: | YB-LF4330 LCD |
Payment & Shipping Terms:
Price: | $284.00 - $935.00/pieces |
---|---|
Packaging Details: | Safety industrial package.<br>Standard export package per pieces .<br>To be negotiated.(Pallet-Container) |
Supply Ability: | 100000 Piece/Pieces per Month |
Detail Information |
|||
Battery Type: | LiFePO4 | Nominal Voltage: | 12.8Volts |
---|---|---|---|
Nominal Capacity: | 200Ah | Energe: | 2560Wh |
Cycle Life: | 2000 Cycles | Charging Current: | 100A |
Water Dust Resistance: | IP55 | Cell&Format: | IFR32700 N60,4S34P |
Casing: | Plastic | Discharge Cut-off Voltage: | 10.0v |
Terminal: | M8 | Port: | Shenzhen Or Hongkong |
High Light: | IP55 lifepo4 72v 100ah battery,48v 170ah lithium battery,12v 170ah lifepo4 battery |
Product Description
Customized Deep Cycle Lithium Iron Phosphate Li-Ion Battery BMS 12v 48v 72v 100ah 170ah 200ah Lifepo4 Battery
In several applications (especially off-grid solar and/or wind), energy efficiency can be of crucial importance.
The round-trip energy efficiency (discharge from 100% to 0% and back to 100% charged) of the average leadacid battery is 80%.
The round-trip energy efficiency of a LiFePo4 battery is 92%.
The charge process of lead-acid batteries becomes particularly inefficient when the 80% state of charge has
been reached, resulting in efficiencies of 50% or even less in solar systems where several days of reserve energy
is required (battery operating in 70% to 100% charged state).
In contrast, a LiFePo4 battery will still achieve 90% efficiency under shallow discharge conditions.
Battery Type | LiFePO4 |
Nominal Capacity | 200Ah |
Cycle Life | 2000 Cycles |
Water Dust Resistance | IP55 |
Casing | Plastic |
Terminal | M8 |
Nominal Voltage | 12.8Volts |
Energe | 2560Wh |
Charging Current | 100A |
Cell&Format | IFR32700 N60,4S34P |
Discharge Cut-off Voltage | 10.0v |
Port | Shenzhen Or Hongkong |
why choose us?
1. Longer Cycle Life , >2000 cycles @1C 100%D0D , Offers up to 20 times longer , cycle life and five times longer , float/calendar life than lead acid battery , helping to minimize replacement cost and reduce total cost of ownership .
2. Superior Safety , Lithium iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact overcharging or short circuit situation .
3. Wider Temperature Range : -20°C-60°℃ .
4. Support 4pcs 12V Batteries Connect In Series To Get48V .
5. Lighter Weight , About 40% of the weight of a comparable lead acid battery A 'drop in' replacement for lead acid batteries .
6. Balancing BMS with balancing function .
about us
Shenzhen YaBo Power Technology Co.,Ltd. YABO power Technology Co.,Ltd is a new energy company, at least 20 years professional
battery manufacturing experience, Has a strong R & D team, design team, business team.Mainly engaged in LiFePO4 battery ,energy storage battery packs,portable power station,mainly providing new energy battery products related to home solar energy storage and outdoor electrical power supply for responding to the national goal of achieving carbon neutrality, reducing carbon emissions and bringing green new energy to the world.
YABO power products are distributed worldwide for use in various electronic products, these include: Wireless communication devices, UPS,Tower Base Station, RV,golf carts,forklifts,yachts,lighting, electrical tools, toys, medicalequipment, solar energy storage systems,backup power systems and electric vehicles.Our batteries have passed ISO9001, CE, RoHS,cB, REACH, FCC, UN38.3 and UL certification.
As a leading worldwide supplier, YABO power current distribution network includes China,Hong Kong, North America, Europe, South America, Southeast Asia and Korea.Our lithium ion, lithium polymer, LiFePO4 batteries,solar generator show high energy
density of 300wh per kg, long cycle life exceed 2,000 cycles, wide temperature work range from -40"C~+ 6 5"C. Currently we are the only supplier of ultra-high power. We believe that our reliable quality products and strong relationships with consumers is
the key to our success. Top technology, Top quality, Top service which is always our aim.With great enthusiasm and loyalty, we are willing to provide you with perfect services,and work together with you to create a better future.
FAQ
Q1. Can I have a sample order?
A. Yes, we welcome sample order to test and check quality.
Q2. What about the lead time?
A. Sample needs 3 days, mass production time needs 5-7 weeks, it depends on order quantity.
Q3. Do you have any MOQ limit?
A. Yes, we have MOQ for mass production, it depends on the different part numbers. 1~10pcs sample order is available. Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A. It usually takes 5-7 days to arrive. Airline and sea shipping is also optional.
Q5. How to proceed with an order?
A. Firstly let us know your requirements or application. Secondly, We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places a deposit for formal order. Fourthly We arrange the production.
Q6. Is it OK to print my logo on the product?
A. Yes. Please inform us formally before our production and confirm the design firstly based on our sample. Q7.Which certificates do you have?
A:We have CE/FCC/ROHS/UN38.3/MSDS ...etc.
Q8. How about warranty?
A:3 year warranty.
